ELG-100-24
ELG-100-24 MEANWELL AC-DC Single output LED driver Constant current (CC) with built-in PFC, Output 24VDC / 4..
$0.00USD
3291 en stock
Spécifications clés
Nom:ELG-100-24
État:Do not Use for New Designs
Format:Box
Série:ELG-100-V
Informations sur le fournisseur
MEANWELL
Produits : 6448
Habituellement expédié sous 2 à 3 jours ouvrables
Qualité garantie
Livraison rapide
Support technique
Spécifications techniques
| Paramètre | Valeur |
|---|---|
| Nom | ELG-100-24 |
| État | Do not Use for New Designs |
| Format | Box |
| Série | ELG-100-V |
| Approbations | BIS, CCC, CE, EAC, ENEC, KCC, MM, RCM, UL |
| Puissance (W) | 96,00 |
| Sous-format | IP67 |
| Largeur (mm) | 63.00 |
| Hauteur (mm) | 35.50 |
| Entrée CA Max | 305,00 |
| Entrée CA Min | 100,00 |
| Applications | Lighting |
| Fabricant | MEAN WELL |
| Type de produit | LED Driver |
| Isolation (V) | 3.750,00 |
| Tension de sortie | 24,00 |
| Puissance de crête (W) | Ninety six |
| Connecteur d'entrée | Cable |
| Fréquence d'entrée | 50 Hz, 60 Hz |
| Contexte long | 199.00 |
| Description longue | LED driver.Specially designed to feed LED strips.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output voltage24vdc.Output intensity4A.Range of output current 0-4A according to demand load.Power:96W.Efficiency typical:88%.Input class I with grounding.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):199 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with LED strips or LED bulbs, which are fed at constant voltage. Working mode constant voltage giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.The series ELG are Led drivers, class I grounded. The own metal box serves to connect the ground of security. You can ask for a version with ground cable from the input (3 wires) by adding-3Y at the end of the model. For example ELG-100-24-3Y.This source can operate in either constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.With metal housing, waterproof to IP67. The series ELG has a high efficiency designed for applications of public lighting, architectural, outdoor or any application of LED lighting need a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. |
| Connecteur de sortie | Cable |
| Type d'entrée CA | Single-phase |
| Garantie (années) | 5,00 |
| Pays d'origine | China |
Description du produit
More details
Caractéristiques principales
- Qualité de niveau industriel
- Conforme RoHS
- Certifié CE
- Garantie d’un an
Détails techniques
LED driver.
