ELG-75-48DA
ELG-75-48DA MEANWELL AC-DC Single output LED driver Constant current (CC) with built-in PFC, Output 48VDC / ..
$0.00USD
3712 en stock
Spécifications clés
Nom:ELG-75-48DA
État:Do not Use for New Designs
Format:Box
Série:ELG-75-V-DA
Informations sur le fournisseur
MEANWELL
Produits : 6448
Habituellement expédié sous 2 à 3 jours ouvrables
Qualité garantie
Livraison rapide
Support technique
Spécifications techniques
| Paramètre | Valeur |
|---|---|
| Nom | ELG-75-48DA |
| État | Do not Use for New Designs |
| Format | Box |
| Série | ELG-75-V-DA |
| Atténuation | DALI |
| Approbations | CCC, CE, EAC, ENEC, KCC, MM, RCM, UL |
| Puissance (W) | 76,80 |
| Sous-format | IP67 |
| Largeur (mm) | 63.00 |
| Hauteur (mm) | 35.50 |
| Entrée CA Max | 305,00 |
| Entrée CA Min | 100,00 |
| Applications | Lighting |
| Fabricant | MEAN WELL |
| Type de produit | LED Driver |
| Isolation (V) | 3.750,00 |
| Puissance de crête (W) | 76.8 |
| Connecteur d'entrée | Cable |
| Fréquence d'entrée | 50 Hz, 60 Hz |
| Contexte long | 180.00 |
| Description longue | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current1600mA.Range of output voltage with current mode constant24 to 48vdcaccording to demand load.Power:76,8 W.Efficiency typical:90%.Regulation DALI0% to 100% of the output intensity. Certificate to DALI.Input class I with grounding.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Length x Width x Height):180 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.The series ELG are LED drivers, class I grounded. The own metal box serves to connect the ground of security. You can ask for a version with ground cable from the input (3 wires) by adding-3Y at the end of the model. For example ELG-75-48DA-3Y.You can also work in voltage mode constant giving a fixed voltage of 48V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing, waterproof to IP67. The series ELG has a high efficiency designed for applications of public lighting, architectural, outdoor or any application of LED lighting need a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US.Compatible with any system DALI. |
| Connecteur de sortie | Cable |
| Type d'entrée CA | Single-phase |
| Garantie (années) | 5,00 |
| Pays d'origine | China |
| Courant de sortie mA | One thousand six hundred |
| Intensité de sortie minimale (mA) | 1.600,00 |
| Intensité de sortie maximale (mA) | 1.600,00 |
Description du produit
More details
Caractéristiques principales
- Qualité de niveau industriel
- Conforme RoHS
- Certifié CE
- Garantie d’un an
Détails techniques
LED driver dimmable.
Documents du produit
Fiche technique
Spécifications techniques et données de performance
Manuel d'utilisateur
Guide d'installation et d'utilisation
