HLG-480H-C2100A
HLG-480H-C2100A MEANWELL AC-DC Single output LED driver Constant Current (CC) with built-in PFC, Output 280V..
$0.00USD
3278 en stock
Spécifications clés
Nom:HLG-480H-C2100A
État:New
Format:Box
Série:HLG-480H-C-
Informations sur le fournisseur
MEANWELL
Produits : 6448
Habituellement expédié sous 2 à 3 jours ouvrables
Qualité garantie
Livraison rapide
Support technique
Spécifications techniques
| Paramètre | Valeur |
|---|---|
| Nom | HLG-480H-C2100A |
| État | New |
| Format | Box |
| Série | HLG-480H-C- |
| Approbations | CCC, CE, ENEC, UL |
| Puissance (W) | 481,00 |
| Sous-format | IP65 |
| Largeur (mm) | 125.00 |
| Hauteur (mm) | 43.80 |
| Entrée CA Max | 305,00 |
| Entrée CA Min | 90,00 |
| Applications | Lighting |
| Fabricant | MEAN WELL |
| Type de produit | LED Driver |
| Isolation (V) | 3.750,00 |
| Puissance de crête (W) | Four hundred eighty one |
| Connecteur d'entrée | Cable |
| Fréquence d'entrée | 50 Hz, 60 Hz |
| Contexte long | 262.00 |
| Description longue | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal boxIP65.Input range90-305Vca47-63Hz.Output in constant current2,1 A.Adjustable by potentiometer (1,05-2,1 A).Range of output voltage with current mode constantOne hundred fourteento229Vccaccording to demand load.Power:481W.Efficiency typical:95%.Potentiometer:this model incorporates 1 external potentiometer that allows us to regulate the maximum output current.Input class I with grounding.Factor corrector, power>0.97to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):262 x 125 x 43.8 mm7 years of warranty.Manufacturer: MEAN WELL.This source can work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. The output current can be adjusted byexternal potentiometerlocated in the housing of the source.The series HLG are LED drivers, class I grounded.With metal housing IP65. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting. |
| Connecteur de sortie | Cable |
| Type d'entrée CA | Single-phase |
| Garantie (années) | 7,00 |
| Pays d'origine | Taiwan |
| Courant de sortie mA | 1050, 1100, 1150, 1200, 1250, 1300, 1350, 1400, 1450, 1500, 1550, 1600, 1650, 1700, 1750, 1800, 1850, 1900, 1950, 2000, 2050, 2100 |
| Intensité de sortie minimale (mA) | 1.050,00 |
| Intensité de sortie maximale (mA) | 2.100,00 |
Description du produit
More details
Caractéristiques principales
- Qualité de niveau industriel
- Conforme RoHS
- Certifié CE
- Garantie d’un an
Détails techniques
LED driver.
