HVG-100-24D
HVG-100-24D MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 4A. 96W, 12-24V. IP67. Timer di..
$0.00USD
4398 en stock
Spécifications clés
Nom (Détails):HVG-100-24D
État (Détails):Requires Minimum Quantities
Format (Détails):Box
Approbations (Détails):UL
Informations sur le fournisseur
MEANWELL
Produits : 6448
Habituellement expédié sous 2 à 3 jours ouvrables
Qualité garantie
Livraison rapide
Support technique
Spécifications techniques
| Paramètre | Valeur |
|---|---|
| Nom (Détails) | HVG-100-24D |
| État (Détails) | Requires Minimum Quantities |
| Format (Détails) | Box |
| Approbations (Détails) | UL |
| Puissance (W) (Détails) | 96,00 |
| Règlement (Détails) | Smart |
| Subformato (Détails) | IP67 |
| Largeur (mm) (Détails) | 68.00 |
| Hauteur (mm) (Détails) | 38.80 |
| Entrée CA max. (Détails) | 528,00 |
| Entrée CA min (Détails) | 180,00 |
| Applications (Détails) | Lighting |
| Fabricant (Détails) | MEAN WELL |
| Type de produit (Détails) | LED Driver |
| Isolement (V) (Détails) | 3.750,00 |
| Puissance crête (W) (Détails) | Ninety six |
| Connecteur d'entrée (Détails) | Cable |
| Fréquence d'entrée (Détails) | 50 Hz, 60 Hz |
| Contexte/Détails (Longue durée) | 236.00 |
| Description longue (Détails) | LED driver dimmable with phase input.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input rangeEighteen0-528Vca47-63Hz.Output in constant current4A.Range of output voltage with current mode constant12 to24vdcaccording to demand load.Power:96W.Efficiency typical:91%.Regulation Smart Dimmingprogrammed at the factory.Input class I with grounding.Factor corrector, power>0,98to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):236 x 68 x 38,8 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.The series HVG are LED drivers, class I grounded.You can also work in voltage mode constant giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing IP67. The series HVG has a high efficiency designed for applications of public lighting, exterior, interior, or any application of LED lighting. Approved HL Class I Division 2 for ex-zones in the US. Complies with the requirements of security at the global level for lighting.The version D with Timer Dimming comes with the curve-regulation of the driver is programmed from the factory according to the customer's specification. Fixed a few periods and some rules of the output and the driver will always use the same curves regardless of the hours that it is turned on. We can set up between 2 and 5 different levels. You can make bends fixed on the basis of a few hours of operation. In this way we can achieve greater energy savings and adjust the brightness levels according to the level of occupation. The programming from the factory cannot be changed.In addition to this setting on the D versions is you can limit the maximum output current, for example if we use a driver 1050mA and you only need to 900mA can be adjusted to the maximum value of the output current.With the version Timer dimming can achieve energy savings most important, always maintaining a level of brightness appropriate and with a stand-alone system that enables us to avoid any maintenance cost. |
| Connecteur de sortie (Détails) | Cable |
| Type d'entrée CA (Détails) | Three-phase |
| Garantie (années) (détails) | 5,00 |
| Pays d'origine (détails) | China |
| Courant de sortie mA (Détails) | Four thousand |
| Intensité de sortie minimale (mA) (Détails) | 4.000,00 |
| Intensité de sortie maximale (mA) (Détails) | 4.000,00 |
Description du produit
More details
Caractéristiques principales
- Qualité de niveau industriel
- Conforme RoHS
- Certifié CE
- Garantie d’un an
Détails techniques
LED driver dimmable with phase input.
